Product Overview

Specifications

Model Name 165-SHU
Input Control Unit AC 95〜240V 50/60Hz
Lamp Used DC 165W ultra-high pressure mercury vapor lamp
Power Consumption (Typical) 230W
Cooling Method Forced cooling
Usage Environment Temp.: 5~35°C, Hum.: 70% or lower RH (ensure that there is no condensation)
Fuse (100V/115V)AC250V6.3A
(220V/240V)AC250V3.15A (midget-type delayed action)
Temperature Protection Equipped w/ thermistor
Weight Approx. 5,500g
Accessories Instruction manual x 1, AC power cord x 1

Optical Specifications

Optical Specifications

External Dimension Diagram (mm)

External Dimension Diagram (mm)

Spectral Distribution

Spectral Distribution

Options

■ Replacement Lamps

Replacement Lamps Replacement Lamps
● Replacement Lamps
Model Name: UV165W (ultra-high pressure mercury vapor lamp)
● Lamp Initial Strength
3,800mW/cm2(Wavelength: 365nm)
*For a radiated distance of 10mm using φ5mm quartz straight-fiber
*Represents test data values and does not indicate guaranteed values.
● Average Lamp Lifespan
2,000 hours (40% of initial luminous energy)
*Represents test data values and does not indicate guaranteed values.
*Regarding lamp replacement:
It is recommended that lamps be replaced after a cumulative lamp usage time of 1,500 to 2,000 hours or less.

■ Light Guide (mm)

Light Guide

● We are also capable of producing light guides that are not shown in our listed offerings. For details, please contact a CSS sales representative.

*Please use heat resistant fibers that are specified to withstand temperatures of 300°C or higher for light guides.
